How Does a Grooved Butterfly Valve Work?
The valve operates through a 90-degree quarter-turn mechanism.
When the disc rotates to the open position, fluid can pass through the valve with relatively low flow resistance. Rotating the disc toward the closed position gradually restricts the flow until the resilient seat contacts the disc and provides shut-off.
The grooved connection remains fixed to the pipeline while the valve can be operated through a handle, gearbox, electric actuator, or pneumatic actuator depending on the configuration.
Key Features
Grooved End Connection
The grooved ends allow the valve to connect directly to grooved piping systems using mechanical couplings, simplifying installation compared with traditional flanged connections.
Fast Installation
Grooved couplings can significantly reduce installation time because they require fewer components and less bolt tightening than conventional flange connections.
Compact Design
The compact butterfly valve structure requires relatively little installation space, making it suitable for mechanical rooms, HVAC systems, and building service pipelines.
Reliable Resilient Sealing
The resilient seat provides dependable shut-off performance and helps protect the sealing surface during normal operation.
Low Operating Torque
The optimized disc and seat design reduces operating resistance and allows efficient operation with manual handles, gearboxes, or actuators.
Easy Maintenance
Grooved connections allow easier valve removal and maintenance without extensive disassembly of the surrounding pipeline.
